Silicon Carbide Protection Plate with NIJ Level IV Certification 10x12 Inch and UHMWPE Composite Laminate Backing
تفاصيل المنتج:
| مكان المنشأ: | هونان، الصين |
| اسم العلامة التجارية: | High Broad |
| إصدار الشهادات: | NIJ 0101.06 Level IV, ISO 9001:2015 |
| رقم الموديل: | HB-SIC-4M-1012 |
| وثيقة: | SIC Ballistic Armor Tiles-P...ad.pdf |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 10 قطع |
|---|---|
| الأسعار: | USD 65-85 / Piece |
| تفاصيل التغليف: | غلاف رغوي EPE فردي مع صندوق مموج، لوح خشب رقائقي من فئة التصدير |
| وقت التسليم: | 5-7 أيام عمل للعينات، 15-25 يوما للطلبات بالجملة |
| شروط الدفع: | T / T ، L / C ، ويسترن يونيون ، باي بال |
| القدرة على العرض: | 5000 قطعة شهريا |
|
معلومات تفصيلية |
|||
| مستوى الحماية NIJ: | المستوى الرابع (.30-06 M2 AP) | صلابة: | 2600 جهد عالي (نوب) |
|---|---|---|---|
| وزن: | 2.8 كجم (طبق واحد) | درجة حرارة التشغيل: | -40 درجة مئوية إلى +70 درجة مئوية |
| كثافة: | 3.15 جم/سم3 | سماكة: | 10.2 ملم (سيراميك متآلف) |
| إبراز: | Affordable NIJ IV SiC Plate,Boron Carbide Alternative Armor,Monolithic Ceramic Rifle Armor |
||
منتوج وصف
Silicon Carbide NIJ Level IV Monolithic Plate — Boron Carbide Performance, Sensible Price
SiC vs Boron Carbide: The Smart Procurement Choice
| Property | Silicon Carbide (SiC) | Boron Carbide (B₄C) | Analysis |
|---|---|---|---|
| Hardness (Knoop) | 2,600 HV | 2,800-3,000 HV | B₄C ~10% harder, but both defeat AP rounds |
| Density | 3.15 g/cm³ | 2.50 g/cm³ | B₄C lighter, but SiC weight difference is minimal in plate form |
| NIJ Level IV Capability | Yes (.30-06 M2 AP) | Yes (.30-06 M2 AP) | Both meet the same threat standard |
| Raw Material Cost | $15-25 / kg | $80-120 / kg | SiC: 75-85% Cheaper Raw Material |
| Finished Plate Cost | 65-85 USD | 120-180 USD | SiC: 35-45% Savings |
| Supply Chain Stability | Mature, widely available | Limited suppliers globally | SiC: Better Availability |
The HB-SIC-4M-1012 monolithic Silicon Carbide plate is engineered for procurement officers who need NIJ Level IV protection at scale. Boron Carbide may offer marginally higher hardness and slightly lower weight, but the 35-45% cost premium is rarely justified for standard-issue armor. Our SiC monolithic design achieves the same AP threat defeat with a supply chain you can count on.
Key Features
- NIJ 0101.06 Level IV Certified: Defeats .30-06 M2 Armor Piercing at 2,880 fps (878 m/s)
- Monolithic 10.2mm SiC Strike Face: Single-piece ceramic eliminates bonding failure points found in multi-tile designs
- UHMWPE Composite Laminate Backing: Multi-layer backing optimizes energy absorption while keeping backface deformation under 25mm
- Swimmer Cut Profile: Reduced shoulder profile for better weapon shouldering and vehicle mobility
- Consistent 2-Round AP Multi-Hit: Tested per NIJ 0101.06 protocol with .30-06 M2 AP projectiles
Who Should Choose SiC Over B₄C?
- Protection units outfitting battalion-level troop protection on a fixed budget
- Law enforcement agencies equipping patrol officers
- Private security contractors needing reliable Level IV protection at scale
- Distributors seeking high-margin ceramic armor with reliable factory supply
Stop paying the Boron Carbide premium. Get NIJ Level IV protection at a sensible price. Inquire now for volume discounts and OEM options.
